IGBT 160 T 65 Technical Datasheet** *(Typical Industrial/Grade Module)*
#### **Key Specifications:** 1. **Voltage Rating:** - Collector-Emitter Voltage (V<sub>CES</sub>): **6500V** - Gate-Emitter Voltage (V<sub>GE</sub>): ±20V
2. **Current Ratings:** - Continuous Collector Current (I<sub>C</sub>): **160A** @ 25°C - Pulsed Current (I<sub>CM</sub>): **320A**
3. **Switching Characteristics:** - Turn-On Time (t<sub>on</sub>): **1.2µs** (typical) - Turn-Off Time (t<sub>off</sub>): **3.5µs** (typical) - Switching Frequency: Up to **5kHz** (recommended)
4. **Thermal Properties:** - Junction-to-Case Thermal Resistance (R<sub>thJC</sub>): **0.12°C/W** - Operating Temperature: **-40°C to +150°C**
5. **Package & Mechanical:** - Module Type: **Dual IGBT with Anti-Parallel Diode** - Mounting: **Screw Terminals** - Weight: **~200g**
6. **Applications:** - Industrial Motor Drives - High-Power Solar Inverters - Railway Traction Systems - Welding Equipment
#### **Why Choose This IGBT?** ✅ High voltage tolerance (6.5kV) for heavy-duty applications ✅ Low switching losses for improved efficiency ✅ Robust thermal performance
